Name: ENVIRONMENTALLY_SENSITIVE_AREAS

Display Field: Shape_Leng

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: For the purposes of this dataset, ESA is as defined in the Stormwater Standards Manual, which follows the definition in the San Diego Regional Municipal Separate Storm Sewer System (MS4) Permit issued by the San Diego Regional Water Quality Control Board. The ESA dataset is a combination of the following data sources: (1) Water bodies listed in the State Water Resources Control Board 2020-2022 Clean Water Act section 303(d) List of Water Quality Limited Segments, (2) water bodies listed in the Water Quality Control Plan for the San Diego Basin as having a RARE beneficial use, and (3) San Diego Multi-Habitat Planning Are (MHPA) Areas downloaded from SanGIS in September 2023. Some corrections to water body locations were made based on the USGS National Hydrography Dataset, internal City of San Diego Stormwater Department channel mapping, and aerial photos. A 200 foot buffer was been added around all of the elements derived from the above sources, except for the portion of Switzer Creek noted below, and then the buffered dataset was dissolved. The underground portion of Switzer Creek (downstream of Balboa Park area) does not have a 200 foot buffer drawn for it. No buffer was applied to this are because most properties the ESA line does not run directly through will have their runoff commingle with runoff from offsite areas and therefore not trigger ESA criteria per the Stormwater Standards Manual.

Service Item Id: f58046dd22dc44618d2f8eb2c5f63d57

Copyright Text: City of San Diego, Stormwater Department

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 6243855.118793473
YMin: 1775280.146931067
XMax: 6471408.376284465
YMax: 1986727.5045473129
Spatial Reference: 102646  (2230)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [0, 100, 255, 94]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape_Leng ( type: esriFieldTypeDouble, alias: Shape_Leng )
• Note ( type: esriFieldTypeString, alias: Note, length: 254 )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape_Length ( type: esriFieldTypeDouble, alias: Shape_Length )
• Shape_Area ( type: esriFieldTypeDouble, alias: Shape_Area )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
