Name: Drain Pump Station

Display Field: STATION

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: This dataset contains pump stations used for the Public Works GIS/SAP Work Management System. The layer is created and maintained to ensure that infrastructure is represented in the appropriate spatial context. This data is maintained by the Stormwater Department, with the Stormwater GIS Team serving as data stewards. The data is updated on an "as-needed" basis.

Service Item Id: f58046dd22dc44618d2f8eb2c5f63d57

Copyright Text: Stormwater Department, City of San Diego

Default Visibility: false

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 6253032.30319497
YMin: 1792564.5706954747
XMax: 6301971.135763302
YMax: 1868996.2452596426
Spatial Reference: 102646  (2230)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Label: Pump Station
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• STATION ( type: esriFieldTypeString, alias: Station Name, length: 5 )
• BLDG_NO ( type: esriFieldTypeDouble, alias: Building Number )
• DIAMETER ( type: esriFieldTypeInteger, alias: Diameter )
• GPM ( type: esriFieldTypeDouble, alias: GPM )
• TOTAL_HP ( type: esriFieldTypeDouble, alias: Total HP )
• HEIGHT ( type: esriFieldTypeDouble, alias: Height )
• X_STREET1 ( type: esriFieldTypeString, alias: Cross Street 1, length: 30 )
• X_STREET2 ( type: esriFieldTypeString, alias: Cross Street 2, length: 30 )
• PMPSTN_ID ( type: esriFieldTypeString, alias: SAP ID, length: 10 )
• ENABLED ( type: esriFieldTypeSmallInteger, alias: Enabled , Coded Values: [0: False] , [1: True] )
• ANCILLARYROLE ( type: esriFieldTypeSmallInteger, alias: Ancillary Role , Coded Values: [0: None] , [1: Source] , [2: Sink] )
• WATERSHED ( type: esriFieldTypeSmallInteger, alias: Watershed Mgmt Area (WMA) , Coded Values: [1: MISSION BAY] , [2: PENASQUITOS] , [3: SAN DIEGO BAY] , ...4 more... )
• DRAWING_NO ( type: esriFieldTypeString, alias: As Built Drawing No, length: 20 )
• INST_YR ( type: esriFieldTypeDate, alias: INST_YR, length: 8 )
• LOC_DESC ( type: esriFieldTypeString, alias: Site Address, length: 40 )
• CDCODE ( type: esriFieldTypeSmallInteger, alias: Council District , Coded Values: [1: 1] , [2: 2] , [3: 3] , ...7 more... )
• CPCODE ( type: esriFieldTypeSmallInteger, alias: Community Area , Coded Values: [1: Balboa Park] , [2: Barrio Logan] , [13: Black Mountain Ranch] , ...55 more... )
• HU ( type: esriFieldTypeInteger, alias: Hydrological Unit , Coded Values: [10722: Anza Borrego] , [4904: Carlsbad] , [10720: Clark] , ...14 more... )
• HA ( type: esriFieldTypeInteger, alias: Hydrological Area , Coded Values: [107226: Agua Caliente] , [49043: Agua Hedionda] , [49028: Aguanga] , ...60 more... )
• HSA ( type: esriFieldTypeInteger, alias: Hydrological Sub Area , Coded Values: [490733: Alpine] , [490926: Alpine Heights] , [490545: Ballena] , ...146 more... )
• SAPOBJNR ( type: esriFieldTypeString, alias: SAPOBJNR, length: 22 )
• IAMFLOC ( type: esriFieldTypeString, alias: IAMFLOC, length: 30 )
• MAPNG_STAT_CD ( type: esriFieldTypeString, alias: MAPNG_STAT_CD, length: 2 , Coded Values: [AB: AS BUILT] , [AN: ABANDONED] , [OP: OPERATIONAL] , ...2 more... )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
